| Supported Operating Systems |
| Operating system |
Windows 7 Professional 64 (available through downgrade rights from Windows 10 Pro) |
| Operating system note |
This
system is preinstalled with Windows 7 Professional software and also
comes with a license and media for Windows 10 Pro software. You may only
use one version of the Windows software at a time. Switching between
versions will require you to uninstall one version and install the other
version. You must back up all data (files, photos, etc.) before
uninstalling and installing operating systems to avoid loss of your
data. |
| Processor |
| Chipset |
Intel® Q170 |
| Processor speed |
2.5 GHz |
| Processor family |
Intel® Core™ i5 processor |
| Processor |
Intel® Core™ i5-6500T with Intel HD Graphics 530 (2.5 GHz, up to 3.1 GHz with Intel Turbo Boost, 6 MB cache, 4 cores) |
| Memory |
| Memory, standard |
8 GB DDR4-2133 SDRAM (1 x 8 GB) |
| Memory slots |
2 SODIMM |
| Drives |
| Hard drive description |
500 GB SATA SSHD |
| Internal drive bays |
One 2.5" |
| Storage type |
SSHD |
| Flash cache |
8 GB SSHD |
| Flash cache note |
The
flash cache module is designed to accelerate the system response
experience and cannot be used as additional storage capacity. It is not
removable by and not accessible to the user. |
| Graphic Subsystem |
| Graphics |
Intel® HD Graphics 530 |
| Graphics |
Integrated |
| Multimedia |
| Audio |
DTS
Studio Soundâ„¢ audio management technology, HD audio with Realtek ALC221
codec (all ports are stereo), microphone and headphone front ports (3.5
mm), audio line-out rear port (3.5 mm), multi-streaming capable,
internal speaker |
| Input devices |
| Keyboard |
HP USB Business Slim Keyboard |
| Pointing device |
HP USB Mouse |
| Connectivity and Communications |
| Network interface |
Intel® i219M GbE |
| Ports |
2 USB 3.0 (1 charging)
1 USB Type-Câ„¢
1 headphone/microphone
1 headphone connector |
| Expansion slots |
2 M.2 |
| Expansion slots note |
1 M.2 PCIe for WLAN. 1 M.2 PCIe for storage |
| I/O Port location |
Front |
| Ports |
4 USB 3.0
1 RJ-45
1 VGA
1 serial (optional)
1 HDMI (optional)
2 DisplayPort (1 optional) |
| I/O Port location |
Back |
| Ports note |
If serial or HDMI is selected, then only 1 Display Port remains available. |
| Battery and Power |
| Power |
65 W 89% efficient (external) |
| Weights |
| Weight |
1.3 kg |
| System Components |
| Form factor |
Mini |
| Security Management |
| Security management |
Security Loop
Hood sensor
HP BIOSphere with Sure Start
HP Active Health
Infineon TPM SLB9670 1.2/2.0 |
| Security management footnote number |
[10] |
|
| Software footnote number |
[8,9] |
| Dimensions |
| Minimum dimensions (W x D x H) |
175 x 177 x 34 mm |
| Warranty |
| Warranty |
3-year
(3-3-3) limited warranty and service offering includes 3 years of
parts, labor and on-site repair. Terms and conditions vary by country.
Certain restrictions and exclusions apply. |
